Industrial wall fan Ø 200 mm for medium spaces
Description
aRk Compact Ø 200 mm – Powerful Wall Fan for Various Spaces
aRk Compact Ø 200 mm is a versatile wall fan that combines high performance and reliability. With an airflow of up to 400 m³/h, quiet operation, and robust construction, it is ideal for use in shops, restaurants, workshops, and smaller industrial spaces.
Key Benefits of aRk Compact Ø 200 mm
Efficient Ventilation of Larger Spaces
The fan enables quick and reliable removal of moisture, heat, and unpleasant odors from spaces. With its capacity of 400 m³/h, it is an excellent choice for ventilating larger areas in commercial and industrial facilities.
Robust and Reliable Construction
The casing made of powder-coated steel ensures corrosion resistance and long-lasting durability. The IPX2 protection allows safe operation of the fan in areas with normal humidity.
Flexible Control
The fan is compatible with 2.5A speed controller, which allows airflow adjustment according to specific room requirements. This functionality is ideal for customizable ventilation solutions.
Quiet and Energy Efficient
Despite its high performance, the fan operates at a noise level of only 54 dB(A), making it suitable for spaces where silence is essential. The 40 W motor ensures low energy consumption and long-lasting operation.
Technical Specifications
| Property | Value |
|---|---|
| Airflow (m³/h): | 400 |
| Noise level (dB(A)): | 54 |
| Power consumption (W): | 40 |
| Static pressure (Pa): | 52 |
| Connection diameter (mm): | 200 |
| Material: | Powder-coated sheet metal |
| Protection class: | IPX2 |
| Motor: | Single-phase asynchronous motor |
| Installation: | Wall-mounted |
Frequently Asked Questions (FAQ)
Where is aRk Compact Ø 200 mm used?
The fan is suitable for ventilating larger spaces such as restaurants, shops, workshops, and industrial areas.
Does it allow for adjustable operation?
Yes, the fan is compatible with the aRo speed controller, allowing for adjustable ventilation intensity.
What are the advantages of a robust design?
The casing made of quality materials and the IPX2 protection ensure corrosion resistance and safe operation even in higher load areas.
Conclusion
aRk Compact Ø 200 mm is the perfect solution for ventilating larger spaces. Its performance, quiet operation, and adaptability provide a top-notch user experience. Check details and order now! Ensure fresh air in your space!
Product Details
- MaterialPowder-coated steel
- Diameter (mm)200
- Airflow (m³/h)400
- Static pressure (Pa)52
- Noise level (dB(A))54
- Electrical power (W)40
- Voltage / frequency / phases220-240 V / 50 Hz / 1F
- IP ratingIPX2
- Installation typewall-mount
- Fan typeaxial
- Controlexternal speed controller (not included)
- Number of speedsadjustable via external speed controller (not included)
- Application area (m²)workshop up to 50 m²
- Warranty (months)24
- Weight (kg)1,97
- Motorball bearings
- Compatible withaRo 100
- Brand
- ReferenceaRk 200
- In stock99998 Items
